750-368
CBEX Elite 100-1200 HP
9-25
— Burner Installation
9.17.2 — 60”, 67”, 78”
Item Qty Description 60” Part # 67” Part # 78” Part #
1 1 Burner Housing to Furnace 656-07965 656-07965 656-07965
2 1 Spud Kit and Pattern 146-00334 146-00334 146-00334
3 1 Burner Housing 040-00853 040-00719 040-00831
4 1 Sized Pipe 057-05027 057-05032 057-05261
5 8oz High Temp Thermo Cement 872-00558 872-00558 872-00558
6 1 Front Head Gasket 032-00105 032-02602 032-00899
7 1 Burner Support to Housing Gasket 032-03170 032-00928 032-00928
8 1 Housing to Front Head Gasket 032-00603 032-02625 032-02625
9 1 Burner Support 085-03463 085-00444 085-00444
10 1 Burner Drawer 429-01668 429-01537 429-01477
11 1 Burner to Housing Gasket 032-00605 X X
