750-177 1-1
CHAPTER 1
GENERAL DESCRIPTION
A. General
The information in this manual applies directly to Cleaver-
Brooks FLX Model boilers in sizes ranging from 1,500,000
to 12,000,000 Btu/hr input.
Fuel Series
700- Gas
100-No.2 0il
200 - Combination Gas & No.2 Oil
Design Pressure
160 psig hot water
15 psig steam
150 psig steam
!
DANGER
CAUTION
The care taken in placing the boiler into initial
service is vital to continuous, reliable operation.
If the boiler is to be used for temporary heat (for
example in new construction), properly treated
water must be used. Failure to do so can be
detrimental to the boiler.
Figure 1-1: FLX Cut Away
A. General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
B. The Boiler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
C. Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
D. Steam Controls (All Fuels) . . . . . . . . . . . . . . . . . . . 1-2
E. Hot Water Controls (All Fuels) . . . . . . . . . . . . . . . . 1-4
