Controller specifications
2
System Bus Address
Two rotary dials are used to manually set the address for System Bus Devices. Turn the dial until the
desired number appears in the slot. The dial closer to the front of the unit is the most significant digit. The
dial closer to the system bus connectors is the least significant digit. No two system bus devices can have
the same address. After address change is a reboot required.
AC power supply
• 104–126 VAC or 207–253 VAC
• 50–60 Hz single phase
• 1 A Input current (rated), 16 A (peak)
