Apex Tool Group P2309HW | 2018-09 9
1
EN
3 Product description
Controller for use in safety-critical tightening.
The controller is primarily used as a control and monitoring
unit for one or more tools at a workstation. Depending on
the peripheral devices that are procured, the controller can
also be installed outside of the work environment.
Software is already installed on the controller. The tighten-
ing settings must be carried out by a qualified person using
the controller or remote PC software (mProRemote) in
order to start fastening work. For further information
regarding software operation, please reference the Pro-
gramming Manual mPro400GCD.
4 Technical Specifications
Ambient Conditions
Power Supply
Normative references
For product-relevant EC Directives, as well as the stan-
dards complied with, see the EC Declaration of Conformity.
System Data
Weight
Features Data
Operation Site Indoors
Ambient Temperature 0...45 °C
1
1. Note the derating. See the System Handbook NeoTek
Storage Temperature -20...70 °C
Type of Cooling Convection (self-cooling)
Relative Humidity 10...90%, No Condensa-
tion
Working Height Up to 3000 m
Above Sea Level
Protection Class DIN EN
60529
IP42
Protection Class
DIN EN61 140
(VDE 0140-1)
I
Degree of Contamination
EN 61010
2
Transient Overvoltage
EN 61010
CAT
Maximum Shock
DIN EN 60068-2-27
15 G
Maximum Vibration
DIN EN 60068-2-5
59.6–160 Hz: 2 G
Features Data
Supply Voltage,
Single Phase
100–240 VAC ± 10%
1
Rated Supply Current 0.2 A
Frequency 50/60 Hz
Peak Current 2.5 A
Rated Power 120 VA max.
Idling 30 VA
1. When operating outside the allowable voltage limits,
the integrated power supply enters a protection mode
and switches off. This protection mode can be reset by
restarting the controller.
Certificates
Issuing agency TÜV SÜD AG
Certificate No. U8 78313 0005
Tested in accordance
with
• UL 61010-1:2012/
R:2016-04
• CAN/CSA–C22.2
No.61010-1:2012/
U2:2016-04
Certificate No.
Tested in accordance
with
N8A 78313 0007
• EN 61010-1:2010
Certificate No. DE3-30943
Tested in accordance
with
• IEC 61010-1:2010
Features Data
System Functions Battery Buffered
Real Time Clock, Buffer
Time: 20 Years (at 20 °C)
Display LC Display With Touch-
screen, 10.4" TFT Liquid
Crystal Display,
Resolution 800 x 600, Con-
nection To Panel & Touch
Possible
Operating System OS-9000, Real-Time Oper-
ating System, Bootable
Without Mechanically Mov-
ing Drives, No UPS
Required
HMI
(Human Machine Inter-
face)
Virtual Keyboard for Alpha-
numeric Inputs
Model Weight*
lb kg
mPro400GCD-M 21.3 9.7
