12 P2309HW | 2018-09 Apex Tool Group
1
EN
6 Storage Access
Abb. 6-1: Storage
7 Items Delivered
Check delivery for transit damage and ensure that all items
have been supplied:
• Controller
• EC Declaration of Conformity
• Hardware Description
• SP-1500
• Warranty
• Mating Connector
mPro400GCD-P_back
2
1
4× S909344
M3×5 DIN912
Pos. Name Function
1 CF Card
(Compact Flash)
Necessary for the operating system and archiving files/applications. Included with controller.
2 SD Card, Optional Function is software-dependent: software update, save/load parameters, data archive files.
Note
Only remove or plug in the CF card when the supply voltage is switched off. Otherwise, serious sys-
tem errors and data loss will result.
Power Cable
EU 230 VAC
Order no.
541683-03
Power Cable
USA 115 VAC
Order no.
541683-01
Plug Locking
Mechanism
Order no.
544004-1
Power Cable
USA 230 VAC
Order no.
541683-02
To Next Page
