English - 59 -
Command received by display
Reply sent
by display for
successful
operation
Byte Number 0 1 2 3 4 5 6 7 8 9 10 11 12
0 1 2 Notes
Header Data
Header
code
Packet
Data
Size
CRC
Action Type
Setting
code
Name Operation L H L H L H L H L H L H
OPS Power
ON BE EF 03 06 00 BA D2 01 00 05 20 01 00 06
OFF BE EF 03 06 00 2A D3 01 00 05 20 00 00 06
GET BE EF 03 06 00 19 D3 02 00 05 20 00 00 1D 00 XY
XY can be either 00 or 01. 00 means
Backlight
GET BE EF 03 06 00 89 D2 02 00 03 20 00 00 1D 00 XY
INCREMENT BE EF 03 06 00 EF D2 04 00 03 20 00 00 06
DECREMENT BE EF 03 06 00 3E D3 05 00 03 20 00 00 06
SET BE EF 03 06 00 89 D2 03 00 03 20 01 XY 06 range: 0x64-0x1E
RESET BE EF 03 06 00 58 D3 06 00 03 20 00 00 06
Auto
Adjust
ON BE EF 03 06 00 32 D4 01 00 19 20 01 00 06 Auto Adjust command is for only VGA.
OFF BE EF 03 06 00 A2 D5 01 00 19 20 00 00 06
Keypad
Lock
ON BE EF 03 06 00 93 97 01 00 11 24 01 00 06
OFF BE EF 03 06 00 03 96 01 00 11 24 00 00 06
GET BE EF 03 06 00 30 96 02 00 11 24 00 00 1D 00 XY
XY can be either 00 or 01. 00 means
Remote
Controller
Lock
ON BE EF 03 06 00 77 97 01 00 16 24 00 00 06
OFF BE EF 03 06 00 E7 96 01 00 16 24 01 00 06
GET BE EF 03 06 00 44 97 02 00 16 24 00 00 1D 00 XY
XY can be either 00 or 01. 00 means
OSD
Menu
ON BE EF 03 06 00 6A 63 01 00 00 37 01 00 06
OFF BE EF 03 06 00 FA 62 01 00 00 37 00 00 06
Contrast
GET BE EF 03 06 00 FD D3 02 00 04 20 00 00 1D 00 XY
SET BE EF 03 06 00 FD D3 03 00 04 20 01 XY 06 range: 0x4E - 0xB2
INCREMENT BE EF 03 06 00 9B D3 04 00 04 20 00 00 06
DECREMENT BE EF 03
06 00 4A D2 05 00 04 20 00 00 06
Auto
Position
EXECUTE BE EF 03 06 00 91 D0 06 00 0A 20 00 00 06
Color
Temperature
INCREMENT BE EF 03 06 00 0B F5 10 00 B0 30 03 00 06
DECREMENT BE EF 03 06 00 CB F8 01 00 B0 30 13 00 06
GET BE EF 03 06 00 C8 F5 02 00 B0 30 00 00 1D 00 XY
XY takes one of the followings:
Clock
INCREMENT BE EF 03 06 00 19 D4 03 00 02 21 03 00 06
Clock commands are for VGA Clock.
They would work independently of the
selected source.
DECREMENT BE EF 03 06 00 19 D5 03 00 02 21 04 00 06
GET BE EF 03 06 00 19 D7 03 00 02 21 06 00 1D 00 XY XY would be in the range of 00 and 64
Phase
INCREMENT BE EF 03 06 00 2F 83 04 00 03 21 00 00 06
Phase commands are for VGA Phase
shift. They would work independently
of the selected source.
DECREMENT BE EF 03 06 00 FE 82 05 00 03 21 00 00 06
GET BE EF 03 06 00 49 83 02 00 03 21 00 00 1D 00 XY XY would be in the range of 00 and 64
H-Position
INCREMENT BE EF 03 06 00 97 82 04 00 01 21 00 00 06
DECREMENT BE EF 03 06 00 46 83 05 00 01 21 00 00 06
GET BE EF 03 06 00 F1 82 02 00 01 21 00 00 1D 00 XY
XY would be in the range of 00 and
64. Central position is 32.
V-Position
INCREMENT BE EF 03 06 00 6B 83 04 00 00 21 00 00 06
DECREMENT BE EF 03 06 00 BA 82 05 00 00 21 00 00 06
GET BE EF 03 06 00 0D 83 02 00 00 21 00 00 1D 00 XY
XY would be in the range of 00 and
64. Central position is 32.
