Clevo P870KM

1 - 22 Right View
Quick Start Guide
1
Right View
Figure 1 - 14
Right View
1. USB 3.0 Port (USB
3.1 Gen 1)
2. Multi-In-1 Card
Reader
3. USB 3.1 Gen 2
(Type C)
Thunderbolt
™ 3
Combo Port # 1
4. USB 3.1 Gen 2
(Type C)
Thunderbolt
™ 3
Combo Port # 2
5. Mini DisplayPort #1
6. Mini DisplayPort #2
7. Security Lock Slot
1
3
4
5
6
Model B

Multi-in-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / RSMMC
SD (Secure Digital) / Mini SD / SDHC / SDXC (Up to UHS-II)
2

Thunderbolt Port Devices
When plugging a device into a Thunderbolt port allow 30 seconds for the system to scan
and recognize the connected device (see over for information on ejecting Thunderbolt Port
devices and “Thunderbolt Ports for Display” on page 1 - 24).
7
