Clevo PB71EF User Manual

Introduction
Specifications 1 - 3
1.Introduction
Audio
High Definition Audio Compliant Interface
S/PDIF Digital Output
Built-In Array Microphone
Two Speakers
One Subwoofer
Sound BlasterX® Pro-Gaming 360°
Communication
1.0M HD PC Camera Module
Built-In 10/100/1000Mb Base-TX Ethernet LAN
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Dual Band Wireless-AC 9260 Wire-
less LAN (802.11ac) + Bluetooth
(Factory Option) Intel® Dual Band Wireless-AC 9560 Wire-
less LAN (802.11ac) + Bluetooth
(Factory Option) Intel® Dual Band Wireless-AC 9462 Wire-
less LAN (802.11ac) + Bluetooth
(Factory Option) Qualcomm® Atheros Killer™ Wireless-AC
1550i Wireless LAN (802.11ac) + Bluetooth
Card Reader
Embedded Multi-In-1 Push-Push Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth Module
Slot 2 for SATA or PCIe Gen3 x4 SSD
Slot 3 for PCIe Gen3 x4 SSD
Interface
One USB 3.1 Gen 2 Type-C Port*
*The maximum amount of current supplied by USB Type-C
ports is 500mA (USB 2.0)/900mA (USB 3.1).
Or
(Factory Option) One Thunderbolt 3 Port**
**The maximum amount of current supplied by Thunderbolt 3
port is 3000mA.
Three USB 3.0 (USB 3.1 Gen 1) Type-A Ports (Including one
AC/DC Powered USB Port)
One DisplayPort 1.3 over USB 3.1 Gen 2 Type-C Port
One Mini DisplayPort 1.3
One HDMI-Out Port
One 2- In-1 Audio Jack (Microphone and S/PDIF Optical)
One 2- In-1 Audio Jack (Headphone and Microphone)
One RJ-45 LAN Jack
One DC-In Jack
Features
Intel® Optane™ Technology
Supports NVIDIA® G-SYNC™ Technology
(NVIDIA® G-SYNC™ Technology is supported by some LCD
panels and RTX series video adapters Only)
Virtual Reality Ready
Windows® Mixed Reality Compatible
(Factory Option) USB Drive
USB 3.1 Gen 2
Note that when a single USB device is plugged
in to a USB 3.1 Gen 2 port the data transfer
speed will be 10Gbps, however when two devic-
es are plugged in to both USB 3.1 Gen 2 ports,
this bandwidth will be shared between the ports.
Environmental Spec
Temperature
Operating: 5°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Removable 6 Cell Smart Lithium-Ion Battery Pack, 62WH
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19.5V, 11.8A (230W)
Dimensions & Weight
399mm (w) * 275mm (d) * 29.9mm (h)
2.9kg (Barebone with 62WH Battery)
