Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery
1. Turn off the computer, turn it over.
2. Remove screws - (Figure 1a).
3. Carefully lift the battery up in the direction of the arrow at point (Figure 1b).
4. Remove the battery off the computer (Figure 1c).
5. Reverse the process to install a new battery (do not forget to replace all the screws and bottom cover).
1 2
3
4
3
Figure 1
Battery Removal
a. Remove the screws.
b. Lift the battery up.
c. Remove the battery.
2
a.
c.
4
b.
3
1
3
3. Battery
• 2 Screws
