Introduction
1 - 2 Specifications
1.Introduction
Specifications
Latest Specification Information
The specifications listed here are correct at the
time of sending them to the press. Certain items
(particularly processor types/speeds) may be
changed, delayed or updated due to the manu-
facturer's release schedule. Check with your
service center for more details.
CPU
The CPU is not a user serviceable part. Ac-
cessing the CPU in any way may violate your
warranty.
Processor
Intel® Atom™ Processor N2600
1.60GHz, 32nm, 1MB L2 Cache, DDR3-800MHz, TDP:
3.5W
Intel® Atom
™ Processor N2800
1.86GHz, 32nm, 1MB L2 Cache, DDR3-1066MHz, TDP:
6.5W
Display
W210CUQ, W215CU:
10.1” (25.65cm) WSVGA TFT LCD (Thickness: 5.2mm)
W211CU:
10.1” (25.65cm) WSVGA TFT LCD (Thickness: 3.6mm)
Core Logic
Intel® NM10 Express Chipset
Memory
One 204 Pin SO-DIMM Socket Supporting DDR3 1066/
1333MHz Memory
(The real memory operating frequency
depends on the FSB of the processor)
Memory Expandable up to 2GB or 4GB* Depending on the
Processor
*Atom
™ N2600 Processors Only Support Up to 2GB of
Memory
BIOS
One 16Mb SPI Flash ROM
Phoenix™ BIOS
Video Adapter (for N2800 Processor)
Intel® GMA 3650 Video Integrated with the N2800
Processor
Total Available Graphics Memory of up to 1790MB
MS DirectX® 9 compatible
Video Adapter (for N2600 Processor)
Intel® GMA 3600 Video Integrated with the N2600
Processor
Total Available Graphics Memory of up to 766MB
MS DirectX® 9 compatible
Storage
One Changeable 2.5" 9.5mm (h) SATA Hard Disk Drive
(Factory Option) External USB DVD Super Multi Drive
Module
Audio
High Definition Audio Compliant Interface
2 * Built-In Speakers
Built-In Microphone
Security
Kensington Lock Slot
BIOS Password
TPM v1.2
Interface
Three USB 2.0 Ports
One Headphone-Out Jack
One Microphone-In Jack
One External Monitor Port
One HDMI-Out Port
One RJ-45 LAN Jack
One DC-in Jack
Keyboard
“WinKey” keyboard (with embedded numeric keypad)
Pointing Device
Built-in Touchpad
www.Teknisi-Indonesia.com
