Clevo W210CUQ - Mainboard Overview - Bottom (Connectors)

Introduction
Mainboard Overview - Bottom (Connectors) 1 - 11
1.Introduction
Mainboard Overview - Bottom (Connectors)
Figure 10
Mainboard Bottom
Connectors
1. External Monitor
Port
2. RJ-45 Lan Port
3. USB Ports
4. LCD Cable
Connector
5. CPU Fan Cable
Connector
6. Headphone-Out
Jack
7. Microphone-In
Jack
8. USB Port
9. HDMI-Out Port
10.DC-In Jack
11. Batery Connector
12.HDD Connector
1
2
3
4
5
6
7
8
9
10
3
12
11
