Clevo W210CUQ User Manual

Disassembly
Removing the System Memory (RAM) 2 - 7
2.Disassembly
4. Gently pull the two release latches ( & ) on the sides of the memory socket in the direction indicated by the
arrows (Figure 3c).
5. The RAM module will pop-up (Figure 3d), and you can then remove it.
6. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot.
7. The module’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the slot as it
will go. DO NOT FORCE the module; it should fit without much pressure.
8. Press the module in and down towards the mainboard until the slot levers click into place to secure the module.
9. Replace the bay cover and screw.
10. Restart the computer to allow the BIOS to register the new memory configuration as it starts up.
3
4
Figure 3
RAM Module
Removal (cont’d.)
c. Pull the release latches.
d. Remove the module.

5. RAM Module
d.
5
3
4
c.
5
www.Teknisi-Indonesia.com
