Clevo W740SU - Removing the Battery; 1; 17; 18

Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery

19. Bottom Cover
23. Battery
•19 Screws
1. Turn the computer off, and turn it over.
2. Remove screws - from the bottom cover (Figure 1a
).
3. Lift the bottom cover from point
(Figure 1b).
4. Remove the bottom cover (Figure 1b).
5. Remove screws - and disconnect cable from the computer (Figure 1c).
6. Lift the battery out of the computer (Figure 1d
).
1
17
18
19
20
21
22
23
Figure 1
Battery Removal
a. Remove the screws.
b. Remove the bottom cov-
er.
c. Remove the screw and
disconnect cable.
d. Lift the battery out.
9
a.
c.
2
4
3 5
6
8
1 7
101113 12
14
15
16
17
20
19
b.
22
18
21
d.
23
