Clevo W740SU - 6; 7

Disassembly
2 - 8 Removing the Keyboard
2.Disassembly
6. Carefully lift up the keyboard off the computer (Figure 5d).
7. Remove the keyboard shielding plate up and off the bottom case (Figure 5e).
8. Reverse the process to install a new keyboard.
6
7
e.
d.
6
7

7.Keyboard Shielding
Plate
Figure 4
Keyboard Removal
(cont’d.)
d. Remove the keyboard.
e. Remove the keyboard
shielding plate.
