Electrical Data – Internal Secondary Pump – PSC Blower
TR Commercial Electrical Table W/ ISP STANDARD PSC HI STATIC PSC
MODEL
VOLTAGE
CODE
RATED
VOLTAGE
VOLTAGE
MIN/MAX
COMPRESSOR
PUMP
FLA
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
QTY RLA LRA
006
G
208-230 /
60 / 1
187.2 / 253 1 2.6 17.7 0.4 0.3 3.3 4.0 15A
E 265 / 60 / 1 238.5 / 291.5 1 2.6 13.5 0.7 0.4 3.7 4.3 15A
009
G
208-230 /
60 / 1
187.2 / 253 1 3.7 22 0.4 0.8 4.9 5.9 15A
E 265 / 60 / 1 238.5 / 291.5 1 3.4 17.5 0.7 0.8 4.9 5.8 15A
012
G
208-230 /
60 / 1
187.2 / 253 1 5.6 32.5 0.8 0.8 7.2 8.6 15A
E 265 / 60 / 1 238.5 / 291.5 1 4.2 31.5 0.7 0.8 5.7 6.8 15A
015
G
208-230 /
60 / 1
187.2 / 253 1 5.6 29 0.8 0.9 7.3 8.7 15A 0.9 7.3 8.7 15A
E 265 / 60 / 1 238.5 / 291.5 1 5.0 28 0.7 0.7 6.4 7.7 15A 0.7 6.4 7.7 15A
018
G
208-230 /
60 / 1
187.2 / 253 1 7.4 33 0.8 0.9 9.1 11.0 15A 0.9 9.1 11.0 15A
E 265 / 60 / 1 238.5 / 291.5 1 6.0 28 0.7 0.7 7.4 8.9 15A 0.7 7.4 8.9 15A
024
G
208-230 /
60 / 1
187.2 / 253 1 12.8 58.3 0.8 1.5 15.1 18.3 30A 2.7 16.3 19.5 30A
E 265 / 60 / 1 238.5 / 291.5 1 9.6 54 0.7 1.2 11.5 13.9 20A 2.9 13.2 15.6 25A
F** 460 / 60 / 3 414 / 506 1 3.6 28 0.7 1.4 5.7 6.6 15A 1.6 5.9 6.8 15A
H
208-230 /
60 / 3
187.2 / 253 1 7.7 55.4 0.8 1.5 10.0 11.9 15A 2.7 11.2 13.1 20A
030
G
208-230 /
60 / 1
187.2 / 253 1 14.1 73 0.8 2.7 17.6 21.1 35A 2.7 17.6 21.1 35A
E 265 / 60 / 1 238.5 / 291.5 1 11.2 60 0.7 2.9 14.8 17.6 25A 2.9 14.8 17.6 25A
F** 460 / 60 / 3 414 / 506 1 4.2 28 0.7 1.6 6.5 7.6 15A 1.6 6.5 7.6 15A
H
208-230 /
60 / 3
187.2 / 253 1 8.9 58 0.8 2.7 12.4 14.6 20A 2.7 12.4 14.6 20A
036
G
208-230 /
60 / 1
187.2 / 253 1 16.7 79 0.8 2.7 20.2 24.4 40A 2.7 20.2 24.4 40A
E 265 / 60 / 1 238.5 / 291.5 1 13.5 72 0.7 2.0 16.2 19.6 30A 2.9 17.1 20.5 30A
F** 460 / 60 / 3 414 / 506 1 5.8 38 0.7 1.2 7.7 9.2 15A 1.6 8.1 9.6 15A
H
208-230 /
60 / 3
187.2 / 253 1 10.4 73 0.8 2.7 13.9 16.5 25A 2.7 13.9 16.5 25A
042
G
208-230 /
60 / 1
187.2 / 253 1 17.9 112 0.8 2.7 21.4 25.9 40A 2.7 21.4 25.9 40A
F** 460 / 60 / 3 414 / 506 1 6.0 44
0.7 1.6 8.3 9.8 15A 1.6 8.3 9.8 15A
H
208-230 /
60 / 3
187.2 / 253 1 13.5 88 0.8 2.7 17.0 20.4 30A 2.7 17.0 20.4 30A
048
G
208-230 /
60 / 1
187.2 / 253 1 21.8 117 1.1 3.3 26.2 31.7 50A 4.8 27.7 33.2 50A
F** 460 / 60 / 3 414 / 506 1 6.2 41 1.3 1.7 9.2 10.8 15A 2.4 9.9 11.5 15A
H
208-230 /
60 / 3
187.2 / 253 1 13.7 83.1 1.1 3.3 18.1 21.5 35A 4.8 19.6 23.0 35A
060
G
208-230 /
60 / 1
187.2 / 253 1 26.3 134 1.1 4.8 32.2 38.8 60A 5.7 33.1 39.7 60A
F** 460 / 60 / 3 414 / 506 1 7.8 52 1.3 2.4 11.5 13.5 20A 2.5 11.6 13.6 20A
H
208-230 /
60 / 3
187.2 / 253 1 15.6 110 1.1 4.8 21.5 25.4 40A 5.7 22.4 26.3 40A
** 460 volt units require a neutral for the Internal Secondary Pump
