ClimateMaster Tranquility TR Series - Electrical Data

22
CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
(TR) Series
Rev.: November 2, 2020
ClimateMaster Water-Source Heat Pumps
Electrical Data – Standard Unit – PSC Blower
TR Commercial Electrical Table STANDARD PSC HI STATIC PSC
MODEL
VOLTAGE
CODE
RATED
VOLTAGE
VOLTAGE
MIN/MAX
COMPRESSOR
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
QTY RLA LRA
006
G
208-230 /
60 / 1
187.2 / 253 1 2.6 17.7 0.3 2.9 3.6 15A
E 265 / 60 / 1 238.5 / 291.5 1 2.6 13.5 0.4 3.0 3.6 15A
009
G
208-230 /
60 / 1
187.2 / 253 1 3.7 22 0.8 4.5 5.5 15A
E 265 / 60 / 1 238.5 / 291.5 1 3.4 17.5 0.8 4.2 5.1 15A
012
G
208-230 /
60 / 1
187.2 / 253 1 5.6 32.5 0.8 6.4 7.8 15A
E 265 / 60 / 1 238.5 / 291.5 1 4.2 31.5 0.8 5.0 6.1 15A
015
G
208-230 /
60 / 1
187.2 / 253 1 5.6 29 0.9 6.5 7.9 15A 0.9 6.5 7.9 15A
E 265 / 60 / 1 238.5 / 291.5 1 5.0 28 0.7 5.7 7.0 15A 0.7 5.7 7.0 15A
018
G
208-230 /
60 / 1
187.2 / 253 1 7.4 33 0.9 8.3 10.2 15A 0.9 8.3 10.2 15A
E 265 / 60 / 1 238.5 / 291.5 1 6.0 28 0.7 6.7 8.2 15A 0.7 6.7 8.2 15A
024
G
208-230 /
60 / 1
187.2 / 253 1 12.8 58.3 1.5 14.3 17.5 30A 2.7 15.5 18.7 30A
E 265 / 60 / 1 238.5 / 291.5 1 9.6 54 1.2 10.8 13.2 20A 2.9 12.5 14.9 20A
F 460 / 60 / 3 414 / 506 1 3.6 28 1.4 5.0 5.9 15A 1.6 5.2 6.1 15A
H
208-230 /
60 / 3
187.2 / 253 1 7.7 55.4 1.5 9.2 11.1 15A 2.7 10.4 12.3 20A
030
G
208-230 /
60 / 1
187.2 / 253 1 14.1 73 2.7 16.8 20.3 30A 2.7 16.8 20.3 30A
E 265 / 60 / 1 238.5 / 291.5 1 11.2 60 2.9 14.1 16.9 25A 2.9 14.1 16.9 25A
F 460 / 60 / 3 414 / 506 1 4.2 28 1.6 5.8 6.9 15A 1.6 5.8 6.9 15A
H
208-230 /
60 / 3
187.2 / 253 1 8.9 58 2.7 11.6 13.8 20A 2.7 11.6 13.8 20A
036
G
208-230 /
60 / 1
187.2 / 253 1 16.7 79 2.7 19.4 23.6 40A 2.7 19.4 23.6 40A
E 265 / 60 / 1 238.5 / 291.5 1 13.5 72 2.0 15.5 18.9 30A 2.9 16.4 19.8 30A
F 460 / 60 / 3 414 / 506 1 5.8 38 1.2 7.0 8.5 15A 1.6 7.4 8.9 15A
H
208-230 /
60 / 3
187.2 / 253 1 10.4 73 2.7 13.1 15.7 25A 2.7 13.1 15.7 25A
042
G
208-230 /
60 / 1
187.2 / 253 1 17.9 112 2.7 20.6 25.1 40A 2.7 20.6 25.1 40A
F 460 / 60 / 3 414 / 506 1 6.0 44 1.6 7.6 9.1 15A 1.6 7.6 9.1 15A
H
208-230 /
60 / 3
187.2 / 253 1 13.5 88 2.7 16.2 19.6 30A 2.7 16.2 19.6 30A
N 575 / 60 / 3 517.5 / 632.5
1 4.9 34 1.4 6.3 7.5 15A 1.4 6.3 7.5 15A
048
G
208-230 /
60 / 1
187.2 / 253 1 21.8 117 3.3 25.1 30.6 50A 4.8 26.6 32.1 50A
F 460 / 60 / 3 414 / 506 1 6.2 41 1.7 7.9 9.5 15A 2.4 8.6 10.2 15A
H
208-230 /
60 / 3
187.2 / 253 1 13.7 83.1 3.3 17.0 20.4 30A 4.8 18.5 21.9 35A
N 575 / 60 / 3 517.5 / 632.5 1 4.8 33 1.4 6.2 7.4 15A 1.8 6.6 7.8 15A
060
G
208-230 /
60 / 1
187.2 / 253 1 26.3 134 4.8 31.1 37.7 60A 5.7 32.0 38.6 60A
F 460 / 60 / 3 414 / 506 1 7.8 52 2.4 10.2 12.2 15A 2.5 10.3 12.3 20A
H
208-230 /
60 / 3
187.2 / 253 1 15.6 110 4.8 20.4 24.3 40A 5.7 21.3 25.2 40A
N 575 / 60 / 3 517.5 / 632.5 1 5.8 38.9 1.8 7.6 9.1 15A 1.9 7.7 9.2 15A
460 volt units require a neutral connection. All “F” voltage units with constant volume ECM require a four wire power supply with neutral. Motors are 265 volt and are wired
between one hot leg and neutral.
All fuses Class RK-5
