TR Series Wiring Diagram Matrix
All current diagrams can be located online at climatemaster.com. Click ‘Commercial Professional’ (go to
‘Resources/literature/wiring diagrams’ in the upper right), use part numbers below to lookup wiring diagrams
Control Type Options Blower Type
Voltage
208-230/60/1, 265/60/1 208-230/60/3 460/60/3 575/60/3
TR006-012 TR015-060 TR024-060 TR024-060 TR024-060
Wiring Diagram Part Number
CXM
Standard
unit, unit with
motorized water
valve, unit
with Internal
secondary
pump
PSC & Hi Static
PSC
96B0500N01 96B0500N11 96B0500N21 96B0500N31 96B0500N31
CXM/LON 96B0500N02 96B0500N12 96B0500N22 96B0500N32 96B0500N32
CXM/MPC 96B0500N03 96B0500N13 96B0500N23 96B0500N33 96B0500N33
DXM2 96B0521N01 96B0521N11 96B0521N21 96B0521N31 96B0521N31
DXM2/LON 96B0521N02 96B0521N12 96B0521N22 96B0521N32 96B0521N32
DXM2/MPC 96B0521N03 96B0521N13 96B0521N23 96B0521N33 96B0521N33
DXM2
Constant Volume
ECM
96B0523N01 96B0523N11 96B0523N21 96B0523N31
DXM2/LON 96B0523N02 96B0523N12 96B0523N22 96B0523N32
DXM2/MPC 96B0523N03 96B0523N13 96B0523N23 96B0523N33
CXM
Constant Torque
ECM
96B0506N01 96B0506N11 96B0506N21 96B0506N31
CXM/LON 96B0506N02 96B0506N12 96B0506N22 96B0506N32
CXM/MPC 96B0506N03 96B0506N13 96B0506N23 96B0506N33
DXM2 96B0527N01 96B0527N11 96B0527N21 96B0527N31
DXM2/LON 96B0527N02 96B0527N12 96B0527N22 96B0527N32
DXM2/MPC 96B0527N03 96B0527N13 96B0527N23 96B0527N33
DXM2
Hydronic
Heating
Constant Volume
ECM
96B0530N01 96B0530N11 96B0530N21 96B0530N31
DXM2/MPC 96B0530N03 96B0530N13 96B0530N23 96B0530N33
CXM
Constant Torque
ECM
96B0511N01 96B0511N11 96B0511N21 96B0511N31
CXM/MPC 96B0511N03 96B0511N13 96B0511N23 96B0511N33
DXM2 96B0532N01 96B0532N11 96B0532N21 96B0532N31
DXM2/MPC 96B0532N03 96B0532N13 96B0532N23 96B0532N33
ClimaDry®
Control Type Options Blower Type
Voltage
208-230/60/1,
265/60/1
208-230/60/3 460/60/3 575/60/3
TR024-060 TR024-060 TR024-060 TR024-060
Wiring Diagram Part Number
DXM2
ClimaDry®
PSC & Hi Static
PSC
96B0524N11 96B0524N21 96B0524N31
DXM2/LON 96B0524N12 96B0524N22 96B0524N32
DXM2/MPC 96B0524N13 96B0524N23 96B0524N33
DXM2
Constant Volume
ECM
96B0525N11 96B0525N21 96B0525N31
DXM2/LON 96B0525N12 96B0525N22 96B0525N32
DXM2/MPC 96B0525N13 96B0525N23 96B0525N33
DXM2
Constant Torque
ECM
96B0528N11 96B0528N21 96B0528N31
DXM2/LON 96B0528N12 96B0528N22 96B0528N32
DXM2/MPC 96B0528N13 96B0528N23 96B0528N33
