ClimateMaster Tranquility TR Series - Unit Physical Data

6
CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
(TR) Series
Rev.: November 2, 2020
ClimateMaster Water-Source Heat Pumps
TR Series 006 009 012 015 018 024 030 036 042 048 060
Compressor (1 each) Rotary Scroll
Factory Charge HFC-410A
- (oz.)
19 20 23 35 43 40 48 50 70 74 82
ECM Fan Motor & Blower
Blower Wheel Size (Dia x w) 6x5 6x5 6x5 9x7 9x7 9x7 9x7 9x8 9x8 10x10 11x10
PSC Fan Motor & Blower
Fan Motor Type/Speeds PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3
Blower Wheel Size (Dia x W) 5x5 5x5 6x5 8x7 8x7 9x7 9x7 9x8 9x8 10x10 11x10
Water Connection Size
Source FPT 1/2” 1/2” 1/2” 1/2” 1/2” 3/4” 3/4” 3/4” 3/4” 1” 1”
Optional HWG FPT 1/2”
Coax Volume (gallons) 0.123 0.143 0.167 0.286 0.45 0.286 0.323 0.323 0.89 0.738 0.939
Vertical
Air Coil Dimensions (H x W) 10x15 10x15 10x15 20x17.25 20x17.25 20x17.25 20x17.25 24x21.75 24x21.76 28x25 28x25
Filter Standard - 1”
Throwaway
10x18 10x18 10x18 20x20 20x20 20x20 20x20 24x24 24x24 28x28 28x28
Weight - Operating (lbs.) 110 112 121 163 168 184 192 213 228 283 298
Weight - Packaged (lbs.) 115 117 126 168 173 189 197 219 234 290 305
Horizontal
Air Coil Dimensions (H x W) 10x15 10x15 10x15 16x22 16x22 16x22 16x22 20x25 20x25 20x35 20x35
Filter Standard - 1”
Throwaway
10x18 10x18 10x18 16x25 16x25 18x25 18x25
20x28 or
2-20x14
20x28 or
2-20x14
1-20x24,
1-20x14
1-20x24,
1-20x14
Weight - Operating (lbs.) 110 112 121 163 168 184 192 213 228 283 298
Weight - Packaged (lbs.) 115 117 126 168 173 189 197 219 234 290 305
Notes: All units have TXV expansion device and 1/2” & 3/4” electrical knockouts.
575 volt fan motors are two speed.
FPT=Female Pipe Thread
Condensate Drain Connection is 3/4” FPT.
For ClimaDry
®
option add 30 lbs (13.6 kg).
Unit Maximum Water Working Pressure
Options Max Pressure PSIG [kPa]
Base Unit 500 [3447]
Internal Secondary Pump (ISP) 145 [999]
Internal Motorized Water Valve (MWV) 300 [2,068]
Internal Auto Flow Valve 300 [2,068]
ClimaDry
®
145 [999]
Use the lowest maximum pressure rating when multiple options are combined.
Unit Physical Data
Tranquility
®
(TR) Series (60 Hz)
