Hydronic Heating Physical Data
TR Series 006 009 012 015 018 024 030 036 042 048 060
Compressor (1 each) Rotary Scroll
Factory Charge R410A - (oz.) 17 18.5 23 35 43 43 48 50 70 74 82
ECM - CV Fan Motor & Blower
Fan Motor - Hybrid (hp) [W] 1/8 1/8 1/4 1/3 1/3 1/2 3/4 3/4 3/4 1 1
Blower Wheel Size - Hybrid (Dia x
W)
6x5 6x5 6x5 9x7 9x7 9x7 10X8T 10X8A 10X8A 12X10T 12X10T
ECM - CT Fan Motor & Blower
Fan Motor - Hybrid (hp) [W] 1/4 1/4 1/4 1/3 1/3 1/2 3/4 3/4 3/4 1 1
Blower Wheel Size - Hybrid (Dia x
W)
6x5 6x5 6x5 9x7 9x7 9x7 10X8T 10X8A 10X8A 12X10T 12X10T
Water Connection Size
FPT - All Other 1/2” 1/2” 1/2” 1/2” 1/2” 3/4” 3/4” 3/4” 3/4” 1” 1”
Horizontal
Air Coil Dimensions (H x W) 10x15 10x15 10x15 16x22 16x22 16x22 16x22 20x25 20x25 20x35 20x35
Filter Standard - 1” Throwaway 10x18 10x18 10x18 16x25 16x25 18x25 18x25
20x28 or
2-20x14
20x28 or
2-20x14
1-20x24,
1-20x14
1-20x24,
1-20x14
Weight - Operating - Hybrid (lbs.) 154 156 165 215 221 253 261 309 324 373 405
Weight - Packaged - Hybrid (lbs.) 159 161 170 220 226 258 266 314 329 378 410
Notes: All units have TXV expansion device and 1/2” & 3/4” electrical knockouts.
FPT=Female Pipe Thread
Condensate Drain Connection is 3/4” FPT.
Unit Maximum Water Working Pressure
Options Max Pressure PSIG [kPa]
Base Unit 300 [2068]
Internal Secondary Pump (ISP) 145 [999]
Internal Auto Flow Valve 300 [2,068]
Use the lowest maximum pressure rating when multiple options are combined.
