Electrical Data – Hybrid Unit with Internal Secondary Pump – ECM Blower
TR Hydr0nic Heat Commercial Electrical Table W/ ISP ECM-CV** ECM-CT
MODEL
VOLTAGE
CODE
RATED
VOLTAGE
VOLTAGE
MIN/MAX
COMPRESSOR
PUMP
FLA
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
QTY RLA LRA
006
G
208-230 /
60 / 1
187.2 / 253 1 2.6 17.7 0.4 1.5 4.1 5.2 15A 2.3 4.9 6.0 15A
E 265 / 60 / 1
238.5 /
291.5
1 2.6 13.5 0.7 1.4 4.0 5.4 15A 2.3 4.9 6.3 15A
009
G
208-230 /
60 / 1
187.2 / 253 1 3.7 22 0.4 1.5 5.2 6.5 15A 2.3 6.0 7.3 15A
E 265 / 60 / 1
238.5 /
291.5
1 3.4 17.5 0.7 1.4 4.8 6.4 15A 2.3 5.7 7.3 15A
012
G
208-230 /
60 / 1
187.2 / 253 1 5.6 32.5 0.8 2.6 8.2 10.4 15A 2.3 7.9 10.1 15A
E 265 / 60 / 1
238.5 /
291.5
1 4.2 31.5 0.7 2.5 6.7 8.5 15A 2.3 6.5 8.3 15A
015
G
208-230 /
60 / 1
187.2 / 253 1 5.6 29 0.8 2.6 8.2 10.4 15A 2.6 8.2 10.4 15A
E 265 / 60 / 1
238.5 /
291.5
1 5.0 28 0.7 2.4 7.4 9.4 15A 1.9 6.9 8.9 15A
018
G
208-230 /
60 / 1
187.2 / 253 1 7.4 33 0.8 2.6 10.0 12.7 20A 2.6 10.0 12.7 20A
E 265 / 60 / 1
238.5 /
291.5
1 6.0 28 0.7 2.4 8.4 10.6 15A 1.9 7.9 10.1 15A
024
G
208-230 /
60 / 1
187.2 / 253 1 12.8 58.3 0.8 3.9 16.7 20.7 30A 3.9 16.7 20.7 30A
E 265 / 60 / 1
238.5 /
291.5
1 9.6 54 0.7 3.2 12.8 15.9 25A 3.2 12.8 15.9 25A
F** 460 / 60 / 3 414 / 506 1 3.6 28 0.7 3.2 6.8 8.4 15A 1.1 4.7 6.3 15A
H
208-230 /
60 / 3
187.2 / 253 1 7.7 55.4 0.8 3.9 11.6 14.3 20A 3.9 11.6 14.3 20A
030
G
208-230 /
60 / 1
187.2 / 253 1 14.1 73 0.8 6.0 20.1 24.4 35A 6.0 20.1 24.4 35A
E 265 / 60 / 1
238.5 /
291.5
1 11.2 60 0.7 4.7 15.9 19.4 30A 3.9 15.1 18.6 25A
F** 460 / 60 / 3 414 / 506 1 4.2 28 0.7 4.8 9.0 10.8 15A 1.5 5.7 7.5 15A
H
208-230 /
60 / 3
187.2 / 253 1 8.9 58 0.8 6.0 14.9 17.9 25A 6.0 14.9 17.9 25A
036
G
208-230 /
60 / 1
187.2 / 253 1 16.7 79 0.8 6.0 22.7 27.7 40A 6.0 22.7 27.7 40A
E 265 / 60 / 1
238.5 /
291.5
1 13.5 72 0.7 4.8 18.3 22.4 35A 3.9 17.4 21.5 30A
F** 460 / 60 / 3 414 / 506 1 5.8 38 0.7 4.8 10.6 12.8 15A 1.5 7.3 9.5 15A
H
208-230 /
60 / 3
187.2 / 253 1 10.4 73
0.8 6.0 16.4 19.8 25A 6.0 16.4 19.8 30A
042
G
208-230 /
60 / 1
187.2 / 253 1 17.9 112 0.8 6.0 23.9 29.2 45A 6.0 23.9 29.2 45A
F** 460 / 60 / 3 414 / 506 1 6.0 44 0.7 4.8 10.8 13.0 15A 1.5 7.5 9.7 15A
H
208-230 /
60 / 3
187.2 / 253 1 13.5 88 0.8 6.0 19.5 23.7 35A 6.0 19.5 23.7 35A
048
G
208-230 /
60 / 1
187.2 / 253 1 21.8 117 1.1 7.5 29.3 35.9 50A 7.5 29.3 35.9 50A
F** 460 / 60 / 3 414 / 506 1 6.2 41 1.3 6.2 12.4 15.3 20A 2.1 8.3 11.2 15A
H
208-230 /
60 / 3
187.2 / 253 1 13.7 83.1 1.1 7.5 21.2 25.7 35A 7.5 21.2 25.7 35A
060
G
208-230 /
60 / 1
187.2 / 253 1 26.3 134 1.1 7.5 33.8 41.5 60A 7.5 33.8 41.5 60A
F** 460 / 60 / 3 414 / 506 1 7.8 52 1.3 6.0 13.8 17.1 20A 2.1 9.9 13.2 20A
H
208-230 /
60 / 3
187.2 / 253 1 15.6 110 1.1 7.5 23.1 28.1 40A 7.5 23.1 28.1 40A
** 460 volt units with Internal Secondary Pump and/or ECM-CV Require a Neutral
