WARNING! When the disconnect switch is closed, high
voltage is present in some areas of the electrical panel.
Exercise caution when working with energized equipment.
CAUTION! Verify that ALL water control valves are open and
allow water ow prior to engaging the compressor. Freezing
of the coax or water lines can permanently damage the heat
pump.
Figure 3: Test Mode Pins
WARNING! 
CAUTION! 
LT1
LT2
LT 1
LT 1
LT 2
LT 2
Short test pins together to enter
Test Mode and speed-up timing
and delays for 20 minutes.
Unit Start-Up Procedure
Motorized Water Valve Option
Corrections
Model Cv MOPD
WPD Adders
GPM PSI FT
006
4.9 150 0.8 0.03 0.06
4.9 150 1.1 0.05 0.12
4.9 150 1.5 0.09 0.22
009
4.9 150 1.1 0.05 0.12
4.9 150 1.7 0.12 0.28
4.9 150 2.2 0.2 0.47
012
4.9 150 1.5 0.09 0.22
4.9 150 2.3 0.22 0.51
4.9 150 3 0.37 0.87
015
4.9 150 1.8 0.13 0.31
4.9 150 2.6 0.28 0.65
4.9 150 3.5 0.51 1.18
018
4.9 150 2.3 0.22 0.51
4.9 150 3.4 0.48 1.11
4.9 150 4.5 0.84 1.95
024
4.9 150 3 0.37 0.87
4.9 150 4.5 0.84 1.95
4.9 150 6 1.5 3.46
030
10.3 150 3.8 0.14 0.31
10.3 150 5.5 0.29 0.66
10.3 150 7.5 0.53 1.22
036
10.3 150 4.5 0.19 0.44
10.3 150 6.8 0.44 1.01
10.3 150 9 0.76 1.76
042
10.3 150 5.3 0.26 0.61
10.3 150 7.9 0.59 1.36
10.3 150 10.5 1.04 2.4
048
10.3 150 6 0.34 0.78
10.3 150 9 0.76 1.76
10.3 150 12 1.36 3.14
060
10.3 150 7.5 0.53 1.22
10.3 150 11.3 1.2 2.78
10.3 150 15 2.12 4.9
ClimaDry
®
Option Corrections - (When
Operating in Non-ClimaDry
®
Mode)
Model
WPD Adders
GPM PSI FT
024
3.0 0.881 2.036
4.5 1.983 4.581
030
3.8 0.622 1.437
5.6 1.351 3.121
036
4.5 0.872 2.015
6.8 1.992 4.602
042
5.3 1.210 2.796
7.9 2.689 6.212
048
6.0 1.551 3.583
9.0 3.490 8.062
060
7.5 1.491 3.445
11.3 3.385 7.820
Model
U.S.
GPM
l/s
Pressure Drop, psi [kPa]*
30°F
[-1°C]
50°F
[10°C]
70°F
[21°C]
90°F
[32°C]
TR
006
0.75 0.05 0.5 (3.7) 0.3 (2.3) 0.2 (1.6) 0.2 (1.6)
1.1 0.07 0.8 (5.3) 0.5 (3.5) 0.4 (2.7) 0.3 (2.2)
1.5 0.09 1.3 (8.8) 0.9 (6.1) 0.7 (4.8) 0.6 (4.0)
TR
009
1.1 0.07 1.3 (9.0) 0.6 (4.4) 0.4 (2.8) 0.3 (1.9)
1.8 0.11 2.1 (14.1) 1.4 (9.4) 1.1 (7.4) 0.9 (6.2)
2.3 0.14 3.5 (24.3) 2.6 (17.9) 2.1 (14.7) 1.8 (12.7)
TR
012
1.5 0.09 1.9 (12.8) 1.1 (7.6) 0.8 (5.3) 0.6 (4.1)
2.3 0.15 3.6 (25.0) 2.6 (17.8) 2.1 (14.3) 1.8 (12.1)
3.0 0.19 6.7 (46.1) 5.0 (34.3) 4.1 (28.3) 3.6 (24.5)
TR
015
1.9 0.12 1.0 (6.9) 0.6 (4.4) 0.5 (3.4) 0.4 (2.8)
2.8 0.18 1.8 (12.4) 1.4 (9.3) 1.1 (7.6) 1.0 (6.9)
3.8 0.24 3.3 (22.7) 2.5 (17.5) 2.1 (14.7) 1.9 (13.1)
TR
018
2.3 0.14 2.1 (14.5) 1.4 (9.9) 1.1 (7.6) 0.9 (6.2)
3.4 0.21 3.4 (23.4) 2.6 (17.6) 2.1 (14.7) 1.8 (12.4)
4.5 0.28 5.9 (40.6) 4.6 (31.5) 3.9 (26.9) 3.4 (23.4)
TR
024
3.0 0.19 2.2 (15.2) 1.7 (11.6) 1.4 (9.6) 1.2 (8.3)
4.5 0.28 4.0 (27.6) 3.2 (22.2) 2.8 (19.3) 2.5 (17.2)
6.0 0.38 7.2 (49.6) 5.9 (40.6) 5.2 (35.8) 4.7 (32.4)
TR
030
3.8 0.24 1.3 (9.0) 0.9 (6.1) 0.7 (4.8) 0.6 (4.1)
5.6 0.35 2.3 (15.8) 1.8 (12.5) 1.5 (10.3) 1.4 (9.6)
7.5 0.47 4.2 (28.9) 3.4 (23.2) 2.9 (20) 2.6 (17.9)
TR
036
4.5 0.28 1.8 (12.4) 1.4 (9.6) 1.2 (8.3) 1.0 (6.9)
6.8 0.43 3.1 (21.4) 2.4 (16.8) 2.1 (14.7) 1.9 (13.1)
9.0 0.57 5.4 (37.2) 4.4 (30.0) 3.8 (26.2) 3.4 (23.4)
TR
042
5.3 0.33 2.3 (15.8) 1.8 (12.1) 1.5 (10.3) 1.3 (9.0)
7.9 0.50 4.3 (29.6) 3.5 (24.2) 3.1 (26.4) 2.8 (19.3)
10.5 0.66 7.9 (54.4) 6.5 (44.8) 5.7 (39.3) 5.2 (35.8)
TR
048
6.0 .038 1.8 (12.4) 1.5 (10.1) 1.3 (9.0) 1.2 (8.3)
9.0 0.57 3.4 (23.4) 3.0 (20.4) 2.7 (18.6) 2.6 (17.9)
12.0 0.76 6.2 (42.7) 5.5 (37.9) 5.1 (35.1) 4.8 (35.1)
TR
060
7.5 0.47 3.4 (23.4) 2.8 (19.2) 2.4 (16.5) 2.2 (15.2)
11.3 0.71 6.8 (46.9) 5.9 (40.8) 5.4 (37.2) 5.0 (34.5)
15.0 0.95 12.6 (86.8) 11.1 (76.8) 10.3 (71.0) 9.6 (66.1)
Table 7: TR Coax Water Pressure Drop
