ClimateMaster Tranquility - Electrical Data; Wiring Diagram Matrix

ClimateMaster Geothermal Heat Pump Systems
THW
11
Residential Products Technical Guide
Electrical Data
Model
Diagram
Number
Voltage Option
THW010 96B0108N05 230/60/1 -
THW010 96B0108N06 230/60/1 VSFP
THW010 96B0108N08 230/60/1 DHW
THW010 96B0108N09 230/60/1 DHW + VSFP
Electrical - Wiring Diagram Matrix
Units with DHW Option
Model
Voltage
Code
Voltage
Min/Max
Voltage
Compressor
*Load
Pump
FLA
*Source
Pump
FLA
ISBP
Pump
FLA
Total
Unit
FLA
Min
Circuit
Amps
Max
Fuse
HACR
Qty RLA LRA
THW010 G 208-230/60/1 197/254 1 20.7 81
1.07 - 1.07 22.8 28 45
1.07 1.07 1.07 23.9 29.1 45
Standard (No DHW)
Model
Voltage
Code
Voltage
Min/Max
Voltage
Compressor
*Load
Pump
FLA
*Source
Pump
FLA
Total
Unit
FLA
Min
Circuit
Amps
Max
Fuse
HACR
Qty RLA LRA
THW010 G 208-230/60/1 197/254 1 20.7 81
1.07 - 21.8 26.9 45
1.07 1.07 22.8 28 45
*Denotes optional items. Consult unit data plate if confi guration is unknown.
