Physical Data
Model 010
Compressor (qty) 1
Factory Charge HFC-410A (oz) [kg] 88 [2.50]
Indoor/Load Water Connection Size
FPT (in) 1
Outdoor/Source Water Connection Size
FPT (in) 1
Domestic Hot Water Connection Size
FPT (in) 3/4
Maximum Working Pressure (Water Side)
Base Unit (PSIG) [kPa] 500 [3445]
DHW Option (PSIG) [kPa] 145 [999]
Internal Source Pump
*
w/Expansion Tank (PSIG) [kPa]
145 [999]
Internal Load Pump
*
w/Expansion Tank (PSIG) [kPa]
145 [999]
Weight - Operating, (lbs) [kg] 455 [207]
Weight - Packaged, (lbs) [kg] 470 [214]
Dual isolation compressor mounting
Balanced Port Expansion Valve (TXV)
Insulated Source and Load Water Coils
*Does not apply to DHW potable water circuit
