Exhaust hose installation:
The exhaust hose and adaptor must be installed or removed in
accordance with the proper mode.
1. Install the adaptor B and adaptor I onto the exhaust hose as
shown in Fig.16a or Fig.16b. Refer to the previous pages for
window kit installation.
2. Install the flexible Exhaust hose as depicted in Fig.17 a&b.
Then push the hook of the Exhaust hose into the hole seat
of the unit in Fig.18.
CAUTION:
Make sure that there are no obstacles around the air outlet
of the exhaust hose (in the range of 20”) in order for the
exhaust system to work properly.
VENT CONTROL feature
The Vent Control is located at the back of the air conditioner.
The OPEN position removes stale air from the room and
exhausts it to the outside. Fresh air is drawn in through normal
passages in the home.
When you don’t need to circulate the room air, set the Vent
Control to the CLOSED position.
