OPERATING INSTRUCTIONS
Error codes and protection code:
EO- Discharge temperature sensor error-
Unplug the unit and plug it back in.
If error repeats, call for service.
E1- Room temperature sensor error-
Unplug the unit and plug it back in.
If error repeats, call for service.
E2- Condenser temperature sensor error -
Unplug the unit and plug it back in. If error
repeats, call for service.
E4- Display panel communication error-
Unplug the unit and plug it back in.
If error repeats, call for service.
P1- Bottom tray is full- Connect the
drain hose and drain the collected
water away. If protection code repeats, call
for service.
Operating Instructions
COOL operation
- Press the "MODE" button until the "COOL”
indicator light comes on.
- Press the ADJUST buttons "+" or " - " to
select your desired room temperature. The
temperature can be set within a range of
17°C-30°C/62°F-88°F.
- Press the “ FAN SPEED" button to choose the
fan speed.
DRY operation
- Press the “MODE” button until the “DRY”
Indicator light comes on.
- Under this mode, you cannot select a fan speed
or adjust the temperature. The fan motor operates
at LOW speed.
- Keep windows and doors closed for the best
dehumidifying effect.
- Do not put the duct in the window.
AUTO operation
- When you set the air conditioner in AUTO mode, it
will automatically select cooling, or fan only
operation depending on what temperature you
have selected and the room temperature.
- The air conditioner will control room temperature
automatically round the temperature point set by
you.
- Under AUTO mode, you cannot select the fan
speed.
FAN operation
- Press the RMODER button until the "FAN" indicator
light comes on.
- Press the "FAN SPEED" button to choose the fan
speed. The temperature cannot be adjusted.
- Do not put the duct to window.
TIMER operation
- When the unit is on, pressing the Timer button will
initiate the Auto-off stop program, the TIMER OFF
indicator light illuminates. Press the UP or down
button to select the desired time. Press the TIMER
button again within 5 seconds, the Auto-on start
program is initiated and the TIMER ON indicator
light illuminates. Press the up or down button to
select the desired Auto-on start time.
- When the unit is off, press the Timer button to
initiate the Auto-on start program, press it again
within five seconds will initiate the Auto-off stop
program.
- Press or hold the UP or DOWN button to change
the Auto time by 0.5 hour increments, up to 10
hours, then at 1 hour increments up to 24 hours.
The control will count down the time remaining
until starting.
- The system will automatically revert back to
display the previous temperature setting if there is
no operation in a five second period.
- Turning the unit ON or OFF at any time or
adjusting the timer setting to 0.0 will cancel the
Auto Start/Stop timer program.
- When a malfunction (E1, E2, E3 or E4) occurs,
the Auto Start/Stop timed program will also be
cancelled.
