MODE display
Displays the current selected mode. Including AUTO,COOL,
DRY, and FAN.
Transmission Indicator
This transmission indicator will light when the remote
Controller transmits signals to the indoor unit.
Temp./Timer display
The temperature setting (from 17°C/62°F) to
30°C/88°F or timer setting (0~24h) will be displayed.
If FAN mode is selected, there will be no display.
ON/OFF display
This indicator will be displayed when the unit is running.
MODE display (FAN mode)
FAN SPEED display
Displays the selected fan speed: AUTO, HIGH, MED
and LOW. Nothing displays when the fan speed is
selected in AUTO speed. When AUTO or DRY Mode
is selected, there will be no signals displayed.
TIMER display
This display area shows the settings of the TIMER.
That is, if only the Auto-on time function is set, it will
display TIMER ON. If only the Auto-off time function
is set, it will display TIMER OFF. If both functions are
set, it will display TIMER ON/OFF which indicates you
have chosen both the Auto-on time and Auto-off time.
LOCK Indicator
LOCK display is displayed when pushing the LOCK button.
Push the LOCK button to clear display.
