CI-154 User’s Manual
Page 52
ASCII
Note
FUNCTION
Jprogram,ID,
cmd
Load named program and ID (optional). Execute command
(optional) Examples:
JPROGRAM 1 (Loads program named PROGRAM 1.)
JPROGRAM 1,LOCATION A,S (Loads PROGRAM 1, sets ID to
LOCATION A, starts counting.)
jabcdefg.xyz
Set stored data file name on USB drive. One to eight
character name with zero to three character extension. Valid
characters: A:Z, a:z, $ % ’ - _ @ ~ ! ( ) { } ^ # &
Mxxnnnnnn
Set Alarm limits/levels on channels 1 to 4 and high/low flow.
Alarm limits are Off to 500000 counts on each channel.
Flow limits are normal at 100%. Setting to 90% and 110%
provides +/-10% before setting an alarm.
Xx range between 01 to 04 and H4/L4 nnnnnn range
between 0 and 500000 for channels 1 to 4 and 0 to 200 on
flow.
M
CHANNEL
01
Smallest Channel
02
Next Channel
03
Next Channel
04
Next Channel
H4
Fourth Analog High (% Flow)
L4
Fourth Analog Low (% Flow)
$dnnnn
(1)
Control display of channels. N=1 or 0
Ex: $d1000 will display only the bottom channel.
$d1001 will display the bottom and top channels.
$pnnnn
(1)
Control printing of channels. N=1 or 0
Ex: $p1000 will print only the bottom channel.
$p1001 will print the bottom and top channels.
$Px
(1)
Enable or disable printer.
X=0: printer off
x=1: print at end of samples
x=2: print alarms only
$Pxy
(2)
Enable or disable printer.
X=0: printer off
x=1: print at end of samples
x=2: print alarms only
y=0: small font
y=1: large font
$Sxy
(1)
Control printing of averages.
X=0: do not print averages after N
x=1: print averages after N
y=0: do not stop after N samples
y=1: stop after N samples
$N/program
name
(2)
Set temporary program name (16 characters max.)
$bwxyz
(2)
Set beeper and alarm behavior. 1=enable 0=disable
w: beep on key x: beep on count
y: beep on alarm z: require acknowledge
$Dx
(2)
Set date mode (Version V2.12 and later.)
x=0: MDY date mode x=1: DMY date mode
