CI-154 User’s Manual
Page 59
The following Holding Registers are in some cases redundant to the registers above
but are arranged so that more information can be acquired more efficiently with a
single block read.
Holding Registers (Read)
Data Contents
40201 – 40206
Date/time.
Month, Day, Year, Hours, Minutes, Seconds
40207 - 40214
Last sample location ID (1st ascii char is on low
byte of register 40207)
40215 - 40222
Last sample unit ID (1st ascii char is on low
byte of register 40215)
40223 - 40230
Last sample user ID (1st ascii char is on low
byte of register 40223)
40231 - 40238
Last sample program name (1st ascii char is on
low byte of register 40215)
40239 - 40241
Last sample Cal due date (Month, Day, Year)
40242
Laser status: 1 = OK
40243
Flow status: 1 = OK
40244 (upper), 40245 (lower)
Sample number
40246 (upper), 40247 (lower)
Status(see Status for details)
40248 (upper), 40249 (lower)
Sample Volume (x100)
(volume unit is in status word)
40250 (upper), 40251 (lower)
Flow rate (x100)
40252 (upper), 40253 (lower)
Channel 1 counts for last sample(smallest size)
(in count mode of instrument)
40254 (upper), 40255 (lower)
Channel 2 counts for last sample
(in count mode of instrument)
40256 (upper), 40257 (lower)
Channel 3 counts for last sample
(in count mode of instrument)
40258 (upper), 40259 (lower)
Channel 4 counts for last sample(largest size)
(in count mode of instrument)
40260 (upper), 40261 (lower)
Elapsed time of sample (1/100’s seconds)
40262 (upper), 40263 (lower)
Channel 1 counts for last sample(smallest size)
(always in total count mode)
40264 (upper), 40265 (lower)
Channel 2 counts for last sample
(always in total count mode)
40266 (upper), 40267 (lower)
Channel 3 counts for last sample
(always in total count mode)
40268 (upper), 40269 (lower)
Channel 4 counts for last sample(largest size)
(always in total count mode)
