General technical data
General technical data - Performance
Size
Size 1 Size 2 SIZE 3 Size 4 Size 5 Size 6
Operation with constant supply temperature
Standard air ow
Nominal air ow l/s 361 611 1278 2000 2638 3333
Nominal air ow m³/h 1300 2200 4600 7200 9500 12000
Max external static pressure (supply) Pa 630 630 630 600 420 630
Max external static pressure (extraction) Pa 630 630 630 630 540 630
Cooling
Total cooling capacity 1 kW 10,60 17,50 38,7 58,4 79,0 95,9
Re-heating capacity 1 kW 2,70 4,20 10,9 14,9 21,3 22,9
Compressor power input 1 kW 2,91 4,92 11,10 15,70 20,40 23,20
EER_C 1 - 4,57 4,41 4,47 4,67 4,91 5,12
Heating
Heating capacity 2 kW 5,93 10,00 21,0 32,9 43,4 54,9
Compressor power input 2 kW 0,71 1,35 2,54 4,22 5,75 8,77
COP_C 2 - 8,38 7,45 8,28 7,80 7,55 6,26
Operation at the maximum available capacity
Standard air ow
Nominal air ow l/s 361 611 1278 2000 2638 3333
Nominal air ow m³/h 1300 2200 4600 7200 9500 12000
Max external static pressure (supply) Pa 630 630 630 600 420 630
Max external static pressure (extraction) Pa 630 630 630 630 540 630
Cooling
Total cooling capacity 3 kW 10,60 17,50 38,7 58,4 79.0 95.9
Compressor power input 3 kW 3,26 5,52 12,5 17,7 22,9 26.1
Additional available capacity to space 3 kW 3,57 5,67 14,0 19.8 27.7 30.9
EER_C 3 - 3,25 3,18 3,10 3,31 3.45 3.68
Heating
Heating capacity 4 kW 10,50 17,80 37,1 58,2 76,8 96,9
Compressor power input 4 kW 2,28 3,77 7,13 11,2 14,4 18,3
COP_C 4 - 4,61 4,72 5,21 5,20 5,33 5,29
Operation with high airow
Maximum air ow
Nominal air ow l/s 528 972 1944 2556 3194 3889
Nominal air ow m³/h 1900 3500 7000 9200 11500 14000
Max external static pressure (supply) Pa 630 470 630 450 345 630
Max external static pressure (extraction) Pa 630 630 630 530 400 630
Cooling
Total cooling capacity 5 kW 9,20 18,20 31,9 45,1 62,0 80,6
Compressor power input 5 kW 1,56 3,38 4,46 6,97 13,8 17,8
EER_C 5 - 5,89 5,38 7,15 6,48 4,50 4,51
Heating
Heating capacity 6 kW 6,00 11,10 22,10 29,10 36,30 44,20
Compressor power input 6 kW 0,54 1,31 2,48 3,11 3,40 5,44
COP_C 6 - 11,10 8,46 8,91 9,36 10,7 8,14
DB = dry bulb
WB = wet bulb
EER_C = Thermodynamic eciency of the system in cooling mode
COP_C = Thermodynamic eciency of the system in heating mode
1. Outdoor air temperature: 35°C D.B./ 24°C W.B.. Extracted air temperature 26°C D.B.. Supply air humidity ratio: 11g/kg. Supply air temperature 24°C D.B.
2. Outdoor air temperature 7°C D.B./ 6.0°C W.B.. External air temperature 20°C D.B. / 12°C W.B.. Supply air temperature 20°C D.B.
3. Outdoor air temperature 35°C D.B./ 24°C W.B.. Extracted air temperature: 26°C D.B.. Supply air humidity ratio: 11g/kg
4. Outdoor air: 7°C D.B./ 6.0°C W.B.. Extracted air temperature: 20°C D.B. / 12°C W.B.. Supply air temperature: 30°C D.B.
5. Outdoor air temperature 35°C D.B./ 24°C W.B.. Extracted air temperature 26°C D.B.. Supply air temperature 22°C D.B.
6. Outdoor air temperature: 7°C D.B./ 6.0°C W.B.. Extracted air temperature: 20°C D.B. / 12°C W.B.. Supply air temperature: 16°C D.B.
