17
Outdoors
Equipment room
Indoors
Only DHW mode is available
12
13
14
15
16
17
8 10
9
2
3
11
4
1
6
6
5
7
ODU
Hydro module
Water flow switch
Wired controller (Accessory)
Y-shaped filter (Accessory)
Check valve (Field supply)
Safety valve (Accessory)
Drain valve (Field supply)
Water expansion tank (Field supply. For model
selection, see page 22.)
Access hole
Water pump (Field supply. For model selection, see
page 22.)
Discharge valve (Field supply)
Water tank (Field supply)
Temperature sensor of the water tank (Accessory)
Tap (Field supply)
Water tank and water pump (Field supply)
One-way valve (Field supply)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
On-site settings of the wired controller:
MENU
OPERATION PARAMETER
FOR SERVICEMAN
OK
2/2
ENTER
SCROLL
FOR SERVICEMAN
1. DHW MODE SETTING
2. HEAT MODE SETTING
4. MULTIPLE SET POINT SETTING
3. WEATHER TEMP.SETTING
5. HOLIDAY AWAY SETTING
6. SERVICE CALL
OK
1/2
ENTER
SCROLL
1. DHW MODE SETTING2. HEAT MODE SETTING
√
YES
NON
√
YES
NON
√
YES
NON
DHW MODE
HEAT MODE
SCROLL
SCROLL
HEAT MODE=NON
Heat mode is invalid.
DHW MODE=YES
DHW mode is invalid.
Temperature settings
t_DI_HIGH TEMP.
t_DI_MAX
DISINFECT
dTtankSH
Ttank_DI
5 °C
65 °C
15 min
210 min
27-05-2019
Sets the desired water tank
temperature, ranging from
25°C to 80°C
04:27 sun
DHW
TANK
ON
45
°C
M0WU00002-00
