TIMER1 is disabled.
Please check the timer setting and temperature
setting.
3. If DHW PUMP RUNNING TIME=NON, choose MENU
> DOMESTIC HOT WATER > DHW PUMP. Press OK.
The following interface is displayed.
DOMESTIC HOT WATER (DHW)
SCROLL
DISINFECT DHW PUMP
6.3 SCHEDULE Function
The SCHEDULE menu contains the following items:
1) TIMER
2) WEEKLY SCHEDULE
3) SCHEDULE CHECK
4) CANCEL TIMER
6.3.1 TIMER Function
If the timer function is enabled, the icon will be
displayed on the main interface of the wired controller. If
the weekly schedule function is enabled, the timer
function will be disabled.
SCHEDULE
SCROLL
SCHEDULE
CHECK
No. START END TIME
00:00
45°C
1
00:00
45°C
2
00:00
00:00
00:00
00:00
45°C
HEAT
HEAT
HEAT
3
TIMER
WEEKLY
SCHEDULE
CANCEL
TIMER
MODE
SCHEDULE
SCHEDULE
CHECK
TIMER
WEEKLY
SCHEDULE
CANCEL
TIMER
SCHEDULE
SCROLL
SCHEDULE
CHECK
No. START END TIME
00:00
45°C
4
00:00
45°C
5
00:00
00:00
00:00
00:00
45°C
HEAT
HEAT
HEAT
6
TIMER
WEEKLY
SCHEDULE
CANCEL
TIMER
MODE
Use ''◄'', ''►'', ''▼'', ''▲'' to scroll and use ''▼'‘, ''▲'' to adjust
the time, the mode and the temperature.
Move to ''■'', press '' OK '' to select or unselect. ( the timer
is selected. the timer is unselected.) six timers can be set.
If you want to cancel the TIMER, change the cursor to '' '',
and press ''OK''. The will become , and the timer is
disabled.
√
√
√
If the start time is later than the end time, the following
interface is displayed.
For example:
Six groups of schedules are set, as shown in the following
table:
No.
1
2
3
4
5
6
START
1:00
7:00
11:30
14:00
15:00
18:00
END
3:00
9:00
13:00
16:00
19:00
23:30
MODE
DHW
HEAT
DHW
HEAT
DHW
HEAT
TEMP.
70
50
70
50
70
50
TIME
1:00
3:00
7:00
9:00
11:30
13:00
14:00
01:00 03:00 09:00 11:30 14:00 15:00
DHW
HEAT
07:00 13:00 16:00 19:00 23:3018:00
OFF
The hydro module will operate as shown in the following
figure:
The operation of the controller
DHW mode is turned ON
DHW mode is turned OFF
HEAT MODE is turned ON
HEAT MODE is turned OFF
DHW MODE is turned ON
DHW MODE is turned OFF
HEAT MODE is turned ON
DHW MODE is turned ON and HEAT MODE
is turned OFF
HEAT mode is turned OFF
HEAT MODE is turned ON and DHW MODE
is turned OFF
15:00
18:00
23:30
Note:
If the start time is the same as the end time, the schedule
is invalid.
To Next Page
