Scenario 2
Only heat mode is available and the hydro module operates in room temperature control mode. (For more information, please
read the Installation Manual.)
Note: The wired controller must be installed indoors, where heating is required. The wired controller is equipped with a
temperature sensor for detecting room temperature.
Scenario 3
Only DHW mode is available. (For more information, please read the Installation Manual.)
04:27 sun
ROOM
SET
ON
24
°C
27-05-2019
27-05-2019
Sets the desired room
temperature, ranging from
17°C to 30°C
Sets the desired water tank
temperature, ranging from
25°C to 80°C
Indicates that the hydro
module operates in room
temperature control mode.
