2 INSTALLATION
2.1 Product receiving
The appliance is supplied packed in several parcels.
Handling must be carried out by appropriate means in
view of the overall weight of the package.
Upon receiving the appliance, check the perfect integrity
of all parts.
In case of damage to the equipment or missing material,
please contact your authorised dealer promptly.
l
WARNING
The manual is an integral part of the product
and therefore it is recommended that you
read it before installing and commissioning
the device and keep it with care for future
reference or transfer to another Owner or
User.
d
IT IS PROHIBITED
disperse in the environment and leave within
the reach of children the packaging material as
it can be a potential source of danger. It must
be disposed of in accordance with current
legislation.
2.2 Size and weight
Indoor unit
27M 35M
Width (mm) 920 920
Depth (mm) 321 321
Height (mm) 211 211
Weight (kg) 11,3 11,3
2.3 Installation - preliminary warnings
l
WARNING
Before installing the indoor unit, consult the
label on the product package to check that the
model number matches the model number of
the outdoor unit.
f
ATTENTION ELECTRIC DANGER
– All electrical connections must be done
by a licensed electrician according to the
provisions of national and local electrical
codes.
– All electrical connections must be made
according to the wiring diagram on the
panels of the indoor and outdoor units.
– If the electrical system has serious safety
problems, stop work immediately. Explain
the situation to the customer and refuse to
install the unit until the security problem has
been resolved.
– The power supply should correspond to
90-100% of the nominal voltage. Insucient
power supply may cause malfunction,
electric shock or fire.
– If the power cables are permanently
installed connected to the electrical system,
install overcurrent protection and a main
power switch with a capacity of 1.5 times the
maximum current of the unit.
– The supply line must have a special
protection upstream against short circuits
and earthing leakage that sections the
system with respect to other utilities. The
technician must choose an approved
dierential circuit-breaker or main circuit
breaker.
– Connect the unit to a single socket of a
dedicated branch of the circuit. Do not
connect other appliances to the same
electrical outlet.
– The air conditioner must be properly
grounded.
– All cables and conductors must be
connected securely. Loosening a conductor
may cause the terminal to overheat, which
in turn may result in fire hazards or product
malfunction.
– The electrical cables must not touch or rest
against the refrigerant pipes, the compressor
or any moving parts of the unit.
