23
Use
BREEZE AWAY OPERATION
1 Press the Breeze Away button on the remote control
to activate the avoiding direct air blowing on the body.
2 Under Breeze Away operation, the system will adjust
the louver angles and fan speed automatically. You
can also choose the fan speed by remote controller.
3 Under Breeze Away operation, the louver moves as
shown below:
Upward Breeze
Away
Fig. 21
m
PRESTARE CAUTELA
For the rooms with large heat load or the
outdoor temperature is too high, you’d better
not choose breezeless operation, this may
result in uncomfortable feeling.
CASCADE OPERATION
1 Press the Cascade button on the remote control to
activate Cascade feature.
2 This feature enables the whole room to be cool or
warm quickly and evenly. The system will adjust the
louver angles and fan speed automatically. You can
also choose the fan speed by remote controller.
3 Under Cascade operation, the louver moves as shown
below:
Upward Cascade
Downward Cascade
Fig. 22
3.4.2 Airflow angle adjustment
ADJUSTING THE VERTICAL AIR FLOW ANGLE
With the unit turned on, use SWING button to adjust
airflow direction.
1 To swing the ventilation slit continuously, press and
hold the SWING button for 3 seconds. Press it again
to stop the automatic function.
Adjustment
range
Fig. 23
l
WARNING
In Cooling or Dehumidifying mode, do not
leave the ventilation slit at an angle that is too
vertical for a prolonged period. In this position
condensation may form on the slit flap, which
may then fall on the floor and furniture (see
“Fig. 23”).
In Cooling or Heating mode, adjustment of the
ventilation slot to an angle that is too vertical
may reduce the performance of the unit due to
restricted airflow.
d
IT IS PROHIBITED
adjust the air vents with your hands, because
doing so could alter the synchronism. In this
case, turn o the unit and disconnect it from the
power mains for a few seconds, then restart
the air conditioner. The air vent will reset.
Downward
Breeze Away
