SIZE 210.6 ÷ 240.6 EXC
1. Internal exchanger (evaporator)
2. External exchanger (condenser)
3. Unit fixing holes
4. Lifting brackets (removable)
5. Electrical panel
6. Power input
7. Sound proof enclosure (optional)
8. Clearance access recommended
SIZE
210.6 EXC 225.6 EXC 240.6 EXC
ST SC/EN ST SC/EN ST SC/EN
Length mm 6680 6680 6680 6680 6680 6680
Depth mm 2228 2228 2228 2228 2228 2228
Height mm 2535 2535 2535 2535 2535 2535
W1 Supporting point kg 611 660 598 634 594 630
W2 Supporting point kg 670 725 1060 1161 1115 1216
W3 Supporting point kg 546 610 430 471 474 515
W4 Supporting point kg 442 458 462 475 461 474
W5 Supporting point kg 561 578 844 880 894 930
W6 Supporting point kg 346 365 308 323 322 336
Operating weight kg 3176 3396 3703 3943 3860 4100
Shipping weight kg 3120 3340 3633 3873 3780 4020
The presence of optional accessories may result in a substantial variation of the weights shown in the table.
DAAT40004_00
DATA/DATE 19/05/2020
W1
W2 W3
W4
W5
W6
