ELECTRICVEHICLE-MOTORMotorComponentTestingandInspection
16
CAUTION
•Donotuseemeryclothtopolishthecommutator.Particlesofemeryareconductiveandmay
short-circuitthecommutatorbars.Donotuseoilorlubricantsonthecommutatororbrushes.
NOTE:Oilonthecommutatormayindicateafaultytransaxleinputshaftoilseal.
ArmatureGroundTest
CAUTION
•Donotsubmergethearmatureinsolvent.
NOTE:Beforetestingthearmature,wipeitcleanwithacleancloth.Removeanycarbondustandmetalparticlesfrom
betweenthecommutatorbars.
1.Withamultimetersetto200ohms,placeoneprobeonthecommutator(1)andtheotheronthearmature
core(2).Themultimetershouldindicatenocontinuity(Figure16-12,Page16-9).Ifthereadingisincorrect,
replacethearmature.
1
2
734
Figure16-12ArmatureTest
2019PrecedentVillager2MaintenanceandServiceManualPage16-9
