MAN. 126 rev.4 Use and maintenance manual S19
62 of 77
• Do not perform any repairs on components of this
MEWP, such as welding, drilling without consulting or written
authorization by the manufacturer (CMC) or it’s authorized
service representatives.
•
• Immense damage can be caused by improper service and
untrained service personnel attempting repairs without proper
training on this aerial work platform. CMC S.r.l. (the
manufacturer), it’s dealers and distributors are not responsible
for your ignorance.
•
•
Always wear proper safety equipment and suitable work clothes
(safety glasses, hard hat, safety toe shoes/boots, proper gloves,
etc).
•
During maintenance operations, be careful not to damage
hydraulic parts. Take great care to avoid contaminating the hydraulic
system.
•
Before performing any maintenance operation that involves
disassembling the hydraulic system, make sure that the system is
not under pressure.
• Consider hydraulic systems always under high pressure that can
cause serious and even fatal injuries. Improperly disassembling
hydraulic components can cause sudden collapse of booms and
other components such as outriggers.
• Do NOT attempt repairs if you are not qualified to do so.
6.11
Fuel endothermic
engine
Diesel engine KUBOTA Z602 E3B, duble cylinder, 4-stroke, overhead
valve, diesel engine.
Cylinder capacity 0,599 l
Highest performance at 3200
min-1
10,8 KW
Fuel type Diesel fuel //
6.12
Maintenance: consumables
Oil: GAZPROMNEFT 32 or equivalent
(hydraulic tank capacity 40 lt)
Lubricant for chains: Interflon Fin Lube EP Plus or equivalent
Main tecnica data:
Composition : Mix of mineral and synthetic oil, jelling agent, Teflon® and
additives.
Density at 20°C ASTM D4052 : 0,88 g/ml ISO VG : n.a.
Dynamic viscosity at 20°C ASTM D2983 : 375 mPas
Grease: Interflon Fin Grease LS2 or equivalent
For boom extension, stabilizers, greasers and bearing
Composition : Complex Lithium-Calcium Soap in mineral oli enriched with
Teflon®* and additives
Work field : from -7°C to +120°C
Before oil replacement, place the oil drip tray in order to avoid
the leakage of the oil in the environment.
