MAN.234 Rev.3 ENG - Use and maintenance manual S19HD (PRO) page
61
of
83
8.4
Quarterly maintenance
(or every 300
hours)
Check the tightening of the slewing ring, gear mo-
USER / CMC
8.5
Maintenance after the first 400 hours
USER / CMC
Register booms clearance. CMC
8.6
Semi-annual maintenance
(or every 750
hours)
(25 micron). USER / CMC
Complete inspection of the entire machine and re-
cording the results in the proper section of the manual.
USER / CMC
8.7
Annual Maintenance
(or every 1500 hours)
CMC
As regards the replacement of hydraulic oil, it is advisable to follow the in-
dications below:
1. Place the machine in the transport configuration and bring the oil to
operating temperature by performing some manoeuvres before
proceeding with the operations described below.
2. Suck the oil from the tank;
3. Remove the hydraulic filter;
4. Replace the filter;
5. Fill the tank by passing the oil through a filter with a degree of filtra-
tion equal to 25 microns.
NOTE: The dipstick to check the oil level is located inside the oil tank cap
located on the floor between the turret and the rear stabilizers. The
hydraulic filters are located at the sides of the stabilisers control sta-
tion.
8.8
Biannual maintenance
Complete inspection of the whole machine and re-
cording the results in the proper section of the manual.
CMC
8.9
Five-year maintenance
General inspection of the whole machine and record-
ing of the results in the proper section of the manual.
CMC
8.10
Safety rules during maintenance
THE NON-OBSERVANCE OF ONE OF THE FOLLOWING
SAFETY RULES CAN SERIOUSLY HARM PEOPLE OR CAUSE
SEVERE DAMAGES TO THINGS OR PARTS OF THE MACHINE.
To ensure the safety of the machine the use of original spare parts
installed by C.M.C. or by authorized repair shops is compulsory:
in fact, some components can be calibrated only c/or C.M.C. or in au-
thorized workshops
.
It is forbidden to perform maintenance operations when the
MEWP moves: make sure that the parts to maintain are motionless
