• Children:
Attribute Description
address Base address of the bar
length Length of the bar in bytes
<custom>
• Parents: slave
• Children:
Attribute Description
register Value of the user defined bar
Below is an example configuration file for a simple LEON3 system.
<?xml version="1.0" standalone="yes"?>
<grxml version="1.0">
<grlib device="0x0" build="4109">
<bus type="AHB" ffactor="1.000000">
<!-- LEON3 SPARC V8 Processor -->
<master vendor="0x1" device="0x3">
</master>
<!-- JTAG Debug Link -->
<master vendor="0x1" device="0x1c" version="1">
</master>
<!-- LEON2 Memory Controller -->
<slave vendor="0x4" device="0xf">
<bar address="0x00000000" length="0x20000000"/>
<bar address="0x20000000" length="0x20000000"/>
<bar address="0x40000000" length="0x40000000"/>
</slave>
<!-- AHB/APB Bridge -->
<slave vendor="0x1" device="0x6">
<bar address="0x80000000" length="0x100000"/>
<bus type="APB" ffactor="1.000000">
<!-- LEON2 Memory Controller -->
<slave vendor="0x4" device="0xf">
<bar address="0x80000000" length="0x100"/>
</slave>
<!-- Generic UART -->
<slave vendor="0x1" device="0xc" irq="2" version="1">
<bar address="0x80000100" length="0x100"/>
</slave>
<!-- Multi-processor Interrupt Ctrl. -->
<slave vendor="0x1" device="0xd" version="3">
<bar address="0x80000200" length="0x100"/>
</slave>
<!-- Modular Timer Unit -->
<slave vendor="0x1" device="0x11" irq="8">
<bar address="0x80000300" length="0x100"/>
</slave>
<!-- General Purpose I/O port -->
<slave vendor="0x1" device="0x1a" version="1">
<bar address="0x80000500" length="0x100"/>
</slave>
</bus>
</slave>
<!-- LEON3 Debug Support Unit -->
<slave vendor="0x1" device="0x4" version="1">
<bar address="0x90000000" length="0x10000000"/>
</slave>
</bus>
</grlib>
</grxml>
