Chapter 3: Connectors & controls
Connectors 11
33333
Connectors & controls
Pin assignment: Connector front view on the rear panel of the Control
Panel.
USB connector
You can use the two USB connectors to connect ancillary equipment.
Pin Description Wire color
1 NMEA in+ Brown
2 NMEA in- Blue
3 NMEA out+ White
4 NMEA out- Green
5 MIC Yellow
6 EAR Grey
7 Hook_PTT Pink
8 12 V Red
9 GND Black
10 GND Orange
Pin Description Wire color
1 5 V Red
2 D- White
3 D+ Green
4 GND Black
