Chapter 2: Installation
8 Installing the Control Panel
.
6. Fasten the four Torx screws.
7. Connect the cables as described in chapter 3.
Mounting the cable relief bracket
A cable relief bracket is included in the delivery. You can fasten it to the rear
panel.
See the previous section for an example on how to mount the cable relief
bracket.
Cable Relief Plate
Screw M3x8 Countersink (3 pcs.)
