Appendix A
AAAAA
Technical specifications
Technical specifications A
Item Specifications
Mounting method Flush mount or bracket
Voltage 10.8 to 31.2 V DC
Power consumption Typical: 18 W active
Peak: 42 W
3.15 A internal fuse (non-serviceable)
Audio output Up to 6 W in 8 Ohm
Interfaces 2 x Ethernet (10/100 Mbit/s)
Accessories connector
Auxiliary connector
Compliance
• IEC 60945
• IEC 60950-1
IP rating IP54
a
a. Estimated.
Ambient temperature -15°C to 55°C
Storage temperature -30°C to 80°C
Heat dissipation Typical 18 W
Compass safe distance 0.6 m
Dimensions W x H x D 191 mm x 145 mm x 61 mm (without mounting
bracket)
Weight 1.1 kg (1.25 kg with mounting bracket)
Display Colour LCD screen with touch
Resolution: 800 x 480 pixels
Pixel size: 0.1905mm
