Instruction Manual - Original Version
4 Definitions
4.1 Technical terms and abbreviations
In the following, the technical terms and abbreviations used in this instruction manual are described.
A person having received the necessary training to carry out a task in a safe and
responsible way
The device that attached on the carriage, handles extrusion and depositioning of
material
The small piece that sits on the end of the print head, that shapes the final form of
the extruded material. Can be 3D printed or machined.
The starting position of the printer, defined as [X,Y,Z,E,U] = [0,0,0,0,0]
4.2 References
1. Mixing/pumping equipment M-tec duo mixer. https://m-tec.com
2. Hilti HIT-Z anchors
https://www.hilti.dk/medias/sys_master/documents/h1c/h4b/9330166333470/Instruction-for-
use-HIT-RE-500-V3-Instruction-for-use-PUB-5307431-000.pdf
3. G-code documentation https://duet3d.dozuki.com/Wiki/G-code
4. Duet3D documentation, firmware updates, maintenance, etc. - https://duet3d.dozuki.com/
