Instruction Manual - Original Version
7.3.13 13 – Beams
Using high pressure water hose or similar, clean all beams / truss modules. Pay special attention to cable
trays.
7.4 Errors
Signal lamp is red, printer will not move
1. Check all E-stops are disengaged. Press
start button on E-box
2. Check that material hopper is installed and
closed. Correct, and press start Button on
E-box.
3. Check that printhead is not loaded with
any external weight, or driven into the
ground
Printhead has crashed into the ground,
Signal lamp is red
To reset printer position:
1. Turn off printer using the Circuit Breaker
on main E-box.
2. Insert “override” key in key-hole located
above circuit breaker on main E-box.
3. Turn key clockwise 90 deg. to override
safety.
4. Turn on machine.
5. Manually move Z-axis upwards (Z+200)
using web control.
6. Turn off machine
7. Turn key Counter Clockwise 90 deg and
remove it from keyhole
8. Turn on printer and press green “start”
button on main E-box.
Material does not feed from extruder
1. Check material consistency in material
hopper. Add a little water to material, until
consistency is more fluid. Manually
extrude until material is coming out of the
nozzle.
2. Extruder pump is not connected to
extruder motor. Insert the mixing shaft
and try again.
Can’t connect to printer (web control)
1. Check, that ethernet cable is correctly
inserted into both printer and computer
2. On duet touch-panel, press “console” to
see the IP of the machine. Check that you
are connecting to the correct IP.
3. Check ethernet settings. If connected
directly through an ethernet cable, IP
