Cable Connections
1 2
Coaxial Digital Audio Cable
Rear Audio/Video Output Jacks
Dolby Pro Logic Surround Receiver
with Digital Coaxial Audio Input
Using an optional coaxial digital audio cable:
Connect one end of the cable to the Coaxial Digital Audio
Out jack located on the rear of the unit.
Connect the other end of the cable to the coaxial digital
audio input jack of the receiver.
1.
2.
