Coca-Cola Freestyle 7000 - Remove Parts Clean Separately

Chapter 5: Monthly Cleaning
Classified – Confidential Page 20 of 46
III. Remove Parts Clean Separately
Step
Action
1.
Inside the Ice Bin locate and remove the Cotter Pin from the Retaining Pin on the
Agitator Bar.
2.
Remove the Retaining Pin from the Agitator Bar.
3.
Remove the Agitator Bar.
