Coca-Cola Freestyle 7000 - Return the Dispenser to Service

Chapter 7: Water Circuit Cleaning
Classified – Confidential Page 45 of 46
VII. Return the Dispenser to Service
Restart the carbonator and return the dispenser to service.
Step
Action
1.
From the Technician Dashboard, Re-Initialize the Macro Module.
Note: After completing re-initialization, the Carb Motor turns on until it refills the carb
tank with water.
2.
From the Technician UI, select CARB WATER until the carb motor turns on, and then
wait for carb motor to stop (<30 seconds).
3.
Repeat Step 2 until continuous carbonated water flows from the nozzle (this should take
3 or 4 cycles).
4.
The dispenser is now ready to be placed back into service.
