Coca-Cola Freestyle 7000 Cleaning

Chapter 7: Water Circuit Cleaning
Classified – Confidential Page 41 of 46
III. Prepare the Water Circuit
Depressurize and purge the water circuits.
Step
Action
1.
In the backroom, turn off the water supply to the dispenser.
2.
Remove the Splash Plate to the front of the dispenser (requires removal of two screws -
one for plate, one for ground wire).
3.
From the Technician UI, select CARB WATER and purge until CO
2
gas blows from the
nozzle. This might take multiple pours, due to time out. The FS7000 carb motor will turn
on and run for two minutes before it times out.
4.
In the backroom, turn off the CO
2
that feeds the dispenser.
5.
From the Technician UI, select CARB WATER until CO
2
gas pressure is relieved from the
system.
6.
From the Technician UI, select PLAIN WATER and purge until no liquid flows from the
nozzle. This should be immediate.
7.
Disconnect the water inlet to the FS7000 carb pump (on the right side) with the quick
disconnect.
IV. Connect the Pump
Connect the electric pump to the water circuits.
Step
Action
1.
Insert both of the fittings on the ends of the Water CIP Tubing Kit into the Sanitizer.
