Chapter 7: Water Circuit Cleaning
Classified – Confidential Page 42 of 46
Insert the straight fitting end into the Cleaning Electric Pump outlet port, and the 90
degree fitting end into the dispenser pump inlet port. Secure both connections with the
locking clip on these ports.
Insert the straight fitting of the Water CIP Tubing Kit into the Sanitizer and then insert
into the Cleaning Electric Pump inlet port and secure the locking clip on this port.
Insert the tee-fitting of the Water CIP Tubing Kit into the Sanitizer and ensure that the
tee-fitting falls to the bottom of the bucket.
Double check all hose connections and ensure they are secure and locked in place.
V. Perform Cleaning
Plug the cleaning electric pump into the nearest 120 VAC electrical outlet and allow the
solution to pump into the system and pressurize both water circuits.
Note: The pump should shut off once the circuits are pressurized.
From the Technician UI, select CARB WATER and flow until the solution in the bucket is
at the 3 gallon mark. This may require multiple separate presses due to timeout.
From the Technician UI, select PLAIN WATER and flow until the solution in the bucket
is at the 2.5 gallon mark. This may require multiple separate presses due to timeout.
Repeat Step 2 until the solution is at the 0.5 gallon mark.
Repeat Step 4 until the remaining solution is depleted from the bucket.
Unplug the cleaning electric pump from the electrical outlet.
