Cochlear Nucleus 7 - Change disposable batteries

Assemble and turn on
With a new, integrated coil design, putting together
your sound processor has never been quicker.
To attach the Slimline
Coil to your Cochlear
Nucleus 7 Sound Processing
Unit, insert the coil cable
into the processing unit
until it clicks into place,
being careful not to twist.
To attach the battery
module hold the battery
module at a slight angle to
the sound processor socket.
If you are using a
rechargeable battery
module, align the raised
marker and arrow on the
battery module towards the
back of the processing unit.
If you are using a disposable
battery module, align
the indents and tamper-
resistant lock on the battery
module towards the back of
the processing unit.
Once aligned, twist the
battery module to attach it
to the processing unit.
2 3 41
Do not twist
12
